Digital Voltmeter - Single range

Model: DVM-Series

Experiment(s):

Specifications

1 . Common Specification

                    Input resistance: 10M Ω
Rated Input: 220 V/50 Hz or 110 V/60 Hz
Power consumption: <20 W
Cabinet: Acrylic body, aluminium bottom
Connectors: BTI-15/ 4 mm banana socket
Dimensions: 180 mm x 150 mm x 200 mm


2 . DVM-301

                    Range: 0-20 V
Resolution: 0.01 V


3 . DVM-302

                    Range: 0-2 V
Resolution: 0.001 V


4 . DVM-201

                    Range: 0-2000 mV
Resolution: 1 mV


5 . DVM-202

                    Range: 0-200 mV
Resolution: 0.1 mV


6 . DVM-203

                    Range: 0-20 mV
Resolution: 0.01 mV


7 . DVM- 204

                    Range: 0-2 mV
Resolution: 0.001 mV


8 . DVM-205

                    Range: 0-200 µ V
Resolution: 0.1 µ V


9 . DVM-303

                    Range: 0-200 V
Resolution: 0.1 V


10 . DVM-401

                    Range: 0-20 V / AC
Resolution: 0.01 V


11 . DVM-402

                    Range: 0-2 V / AC
Resolution: 0.001 V


12 . DVM-403

                    Range: 0-200 mV / AC
Resolution: 0.1 mV


13 . DVM-404

                    Range: 0-20 mV / AC
Resolution: 0.01 mV
