Reference: Lab Experiments Journal vol-14, No.4, Page-294

Solar constant

Model: SC-1506

Experiment(s):

Determination of Solar constant

Specifications

1 . Aluminium rod arrangement with specific surface exposed

                    Aluminium rod insulated on sides except on surface


2 . Thermometer

                    Type: Digital, probe type
Range: 300 °C
Resolution: 0.1 °C


3 . Temperature data acquisition system (data logger)

                    No. of channels: One
Sensor: Thermometer probe
Temperature logging interval:  Selectable form 1 sec to 30 mins
Software: Provided with PLXDAQ software
Software capabilities: Acquires date and time from system and logs corresponding temperatures at set interval
Interface: USB
Output: Logs directly to M S Excel
Power requirement:
Rated Input: 220 V/50 Hz
or 110 V/60 Hz
Power Consumption: <20 W
